sys_time_arch.c File Reference

linux timing functions More...

#include "mcu_periph/sys_time.h"
#include <stdio.h>
#include <pthread.h>
#include <sys/timerfd.h>
#include <time.h>
#include "rt_priority.h"
#include "std.h"
#include <unistd.h>
Include dependency graph for sys_time_arch.c:

Go to the source code of this file.

Macros

#define SYS_TIME_THREAD_PRIO   29
#define NSEC_OF_SEC(sec)

Functions

void sys_tick_handler (void)
void * sys_time_thread_main (void *data)
void sys_time_arch_init (void)
uint32_t get_sys_time_usec (void)
 Get the time in microseconds since startup.
uint32_t get_sys_time_usec100 (void)
 Get the time in 100microseconds since startup.
uint32_t get_sys_time_msec (void)
 Get the time in milliseconds since startup.
void sys_time_usleep (uint32_t us)
 Sleep.
void sys_time_msleep (uint32_t ms)
 Sleep.
uint32_t sys_time_rtc_millisecond (void)
 Get the RTC time in milliseconds since midnight.
void sys_time_rtc_set (uint32_t unix_time, uint16_t unix_ms)
 The system clock is not changed.

Variables

static struct timespec startup_time

Detailed Description

linux timing functions

Definition in file sys_time_arch.c.

Macro Definition Documentation

◆ NSEC_OF_SEC

#define NSEC_OF_SEC ( sec)
Value:
((sec) * 1e9)

Definition at line 51 of file sys_time_arch.c.

Referenced by sys_time_thread_main().

◆ SYS_TIME_THREAD_PRIO

#define SYS_TIME_THREAD_PRIO   29

Definition at line 42 of file sys_time_arch.c.

Referenced by sys_time_thread_main().

Function Documentation

◆ get_sys_time_msec()

uint32_t get_sys_time_msec ( void )

Get the time in milliseconds since startup.

Returns
milliseconds since startup as uint32_t

Definition at line 205 of file sys_time_arch.c.

References startup_time.

◆ get_sys_time_usec()

uint32_t get_sys_time_usec ( void )

Get the time in microseconds since startup.

WARNING: overflows after 71min34seconds!

Returns
current system time as uint32_t

Definition at line 160 of file sys_time_arch.c.

References startup_time.

◆ get_sys_time_usec100()

uint32_t get_sys_time_usec100 ( void )

Get the time in 100microseconds since startup.

WARNING: overflows after 7000 minutes!

Returns
current system time as uint32_t

Definition at line 183 of file sys_time_arch.c.

References startup_time.

◆ sys_tick_handler()

◆ sys_time_arch_init()

void sys_time_arch_init ( void )

Definition at line 97 of file sys_time_arch.c.

References sys_time::cpu_ticks_per_sec, sys_time::resolution, sys_time::resolution_cpu_ticks, startup_time, and sys_time_thread_main().

Here is the call graph for this function:

◆ sys_time_msleep()

void sys_time_msleep ( uint32_t ms)

Sleep.

Parameters
msmilliseconds

Definition at line 228 of file sys_time_arch.c.

References sys_time_usleep().

Here is the call graph for this function:

◆ sys_time_rtc_millisecond()

uint32_t sys_time_rtc_millisecond ( void )

Get the RTC time in milliseconds since midnight.

Returns
milliseconds since midnight as uint32_t

Definition at line 232 of file sys_time_arch.c.

◆ sys_time_rtc_set()

void sys_time_rtc_set ( uint32_t unix_time,
uint16_t unix_ms )

The system clock is not changed.

Set the RTC to the UTC unix time (architecture specific, may do nothing).

Definition at line 245 of file sys_time_arch.c.

◆ sys_time_thread_main()

void * sys_time_thread_main ( void * data)

Definition at line 53 of file sys_time_arch.c.

References fd, get_rt_prio(), NSEC_OF_SEC, sys_time::resolution, sys_tick_handler(), and SYS_TIME_THREAD_PRIO.

Referenced by sys_time_arch_init().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ sys_time_usleep()

void sys_time_usleep ( uint32_t us)

Sleep.

Parameters
usmicroseconds

Sleep.

using intermediate 64 bits variable to avoid wrapping

max sleep time is around 10 days (2^32 / CH_CFG_ST_FREQUENCY) at 10kHz

Definition at line 223 of file sys_time_arch.c.

Variable Documentation

◆ startup_time

struct timespec startup_time
static
